eMCP
Self-developed flash memory controller chip, self-developed firmware, the controller chip, NAND and LPDDR integrated in a multi-chip package, reduce system development time and PCB board area, effectively reduce signal interference, stable data transmission rate.
Consult Now
Product Parameters
Product Features
Application Areas
Product Parameters
CGP
| Product type | Product model | Capacity | eMMC Capacity | eMMC Controller | NAND | DRAM | DRAM Capacity | DRAM Speed | Temperature (℃) |
| eMCP | RS75108M4H03S03F | 1+8GB | 8GB | ATM002 | MLC | LPDDR3 | 1GB | 933MHz | -25 ~ 85 |
| eMCP | RS75216M4H03S06F | 2+16GB | 16GB | ATM002 | MLC | LPDDR3 | 2GB | 933MHz | -25 ~ 85 |
| eMCP | RS77232N4C01Y01F | 2+32GB | 32GB | ATM002 | TLC | LPDDR4X | 2GB | 1866MHz | -25 ~ 85 |
| eMCP | RS77464N4M15S16G | 4+64GB | 64GB | ATM003 | TLC | LPDDR4X | 4GB | 2133MHz | -25 ~ 85 |
| eMCP | RS774T7N4C02Y06G | 4+128GB | 128GB | ATM003 | TLC | LPDDR4X | 4GB | 2133MHz | -25 ~ 85 |
Scroll Mouse
Product Features
Strong autonomy and controllability
Self-developed eMMC flash controller
High integration
self-developed firmware
High speed data transmission
strong autonomous controllability
Good compatibility
Integrating multiple chips in a single package reduces board-to-board connectivity
Firmware upgradable
Supports high-speed data transmission
High cost performance
Conforms to the JEDEC eMMC5.1 standard protocol and is backward compatible with mainstream Host platforms
Application Areas
